# Corresponding Angles

Corresponding angles are formed when two parallel lines are intersected by a third line called the transversal. In the figure below, the parallel lines k and l are intersected by the transversal line t:

The four pairs of corresponding angles are:

∠1 and ∠5

∠2 and ∠6

∠3 and ∠7

∠4 and ∠8

They are corresponding angles because they occupy the same relative position.

## Corresponding angles postulate

The corresponding angles postulate says when two parallel lines are intersected by a transversal, the resulting corresponding angles are congruent.

Let's take a look at the following figure:

According to the corresponding angles postulate, if l and m are parallel (l ∥ m) and intersected by the transversal n, then ∠1 and ∠2 are congruent $\mathrm{\angle 1}\cong \mathrm{\angle 2}$ .

The converse of this statement is also true. If l and m are intersected by a transversal in such a way that the corresponding angles formed are congruent, then l ∥ m.

## Exterior and interior angles

For each pair of corresponding angles, one angle is an exterior angle and the other is an interior angle. For example, ∠1 is an exterior angle because it falls outside of the parallel lines, while ∠5 is an interior angle because it rests between the parallel lines:

## Alternate, consecutive, and vertical angles

While corresponding angles fall on the same side of the transversal, alternate angles fall on opposite sides of the transversal. For example, ∠4 and ∠6 are alternate angles:

Since ∠4 and ∠6 are also exterior angles, they are called alternate exterior angles, while ∠3 and ∠5 are alternate interior angles.

Like corresponding angles, consecutive angles fall on the same side of the transversal. Consecutive interior angles are both inside of the parallel lines (ex. ∠2 and ∠5), while consecutive exterior angles are both outside of the parallel lines (ex. ∠4 and ∠7).

In the above figure, you can also see vertical angles, which are a pair of opposites formed by intersecting lines (ex. ∠1 and ∠3).

## Corresponding angles in polygons

Corresponding angles can also be found in similar and congruent polygons. For example, take a look at the following similar pentagons:

In the figure, ∠A and ∠V are corresponding angles. So are ∠C and ∠X.

## Practice questions on corresponding angles

a. In the above figure, what is the transversal?

Line n

b. In the above figure, which lines are parallel?

Lines l and m

c. In the above figure, what are ∠1 and ∠2?

Corresponding angles

d. In the above figure, what are ∠2 and ∠4?

Vertical angles

e. In the above figure, what are ∠1 and ∠7?

Alternate exterior angles

f. In the above figure, what are ∠3 and ∠8?

Consecutive interior angles

g. In the above figure, what are ∠2 and ∠8?

Alternate interior angles
