Graphing: Scale and Origin

Most often, when we use a coordinate graph , each mark on the axis represents one unit, and we place the origin—the point ( 0 , 0 ) —at the center.

Math diagram

However, sometimes, if we have coordinates that are large numbers, we may need to scale the axes differently.  In the graph below, each mark on the axis represents 500 units.

Math diagram

Also, note that since none of our coordinates were negative, we placed the origin in the bottom left, instead of the center.

In other situations, we may need to scale the x -axis and the y -axis differently.

For example, consider the line y = 0.005 x . If we graph it on a normal grid, with intervals of 1 unit on both axes, we can hardly see it as it’s too close to the x -axis.

Math diagram

Even if we zoom in, it doesn’t solve the problem.

Math diagram

However, if we use an interval of 1 on the x -axis, and an interval of 0.01 on the y -axis, it’s easier to see the line.

Math diagram

Sometimes, when we want to show changes over a small range of x and/or y values, it's hard to avoid having lots of blank space in a graph. The example below shows one way to deal with this.


    The table shows the average price of electricity per kilowatt-hour in various months in the year 2004 .

    Month Jan Feb Mar Apr May Jun
    Price ($) 0.091 0.091 0.091 0.091 0.093 0.099


    Month Jul Aug Sep Oct Nov Dec
    Price ($) 0.099 0.100 0.099 0.094 0.092 0.092

    (Source: Consumer Price Index-Average Price Data, Bureau of Labor Statistics.)
    If we want to draw a line graph to analyze the price variations, what scales of the axes should be used?

    Note that the prices are precise to three decimal places, and are all clustered in the range 0.090 0.100 .

    If we scale the y -axis in units of 0.01 , all the action occurs in a tiny part of the image.

    Math diagram

    In this case you can use a jagged line just above the origin on the y -axis to indicate that some y -values are not shown, and then use a finer scale of 0.001 on the y -axis.

    Math diagram
